Machine Data
Technical Specifications
Spindle nose diameter2.189"
Spindle nose thread2-3/16" - 10 R.H.
Maximum fixture diameter9"
to spindle13"
Travel of cross slide4-1/2"
Cross slide power feed range1/4" to 10" per min..
Low speeds125 to 1100 rpm
High speeds1100 to 3000 rpm
Overview
Machine Overview
Spindle nose diameter: 2.189" Spindle nose thread: 2-3/16" - 10 R.H. Maximum fixture diameter: 9" Maximum distance from face of turret to spindle: 13" Travel of cross slide: 4-1/2" Cross slide power feed range: 1/4" to 10" per min.. Spindle speeds: 3 Selector variable speed machines Low speeds: 125 to 1100 rpm High speeds: 1100 to 3000 rpm
